Product Description
MP Ranger, 3″ Rugged Mobile Printer, WIFI, BT, NFC, USB-C, 2600MAH, IOS, Windows, Android, includes belt clip
Mobile printer for mobile receipt / label issuance for logistics and delivery
MP Ranger is a latest generation mobile printer and represents the evolution of Custom’s range of mobile printers.
It can print on thermal paper in roll format, either on plain paper or peel-off format labels. Complete with sensors for displaying status and battery level, it allows the printing of 1D and 2D barcodes (QRCODE). It can handle rolls with paper width of 76.2 mm or 80 mm using the special reducer included in the package, and is designed to be used in outdoor working contexts, thanks to the IP54 protection to resist splashing of liquids and dust for use in adverse weather conditions and resistance to falls from 1 meter.
The operational equipment is completed by a clip for belt fastening and as an accessory the practical case with shoulder strap is available for greater protection. The printer is equipped with different charging options, from simple connection via USB Type-C to positioning on single charging cradles. MP Ranger can be connected to any mobile device, from simple phones, to specialized terminals, to handheld mobile computers and tablets with Bluetooth and Wi-Fi functionality thanks to the Wireless technology.
MP Ranger features
- MOBILE AND HIGH SPEED PRINTING, BOTH ON PAPER AND ON LABELS
- HIGH AUTONOMY AND INTELLIGENT BATTERY, PROVIDING INFORMATION ABOUT ITS STATUS
- WIRELESS TECHNOLOGY WITH WI-FI AND BLUETOOTH: SIMPLE PAIRING THANKS TO NFC
- IP54 PROTECTION AGAINST LIQUIDS AND DUST – IDEAL FOR OUTDOOR USE
- DIFFERENT CHARGING OPTIONS: VIA USB OR SINGLE CRADLES
PrinterSet to update logos, edit characters, set operating parameters and update the printer firmware. It allows you to create a file including the different SW customizations and send them to the printer via the interface provided, for easy and fast setting.
MP Ranger printer is equipped with Android™ libraries for print management and monitoring, Android SDK containing sample sources for interfacing with the library. Windows® drivers compatible with win7 win8, win8.1, win10 (32/64 bit support) versions are available.
Specifications
- Weight: 1 lb
- Width: 4.9"
- Depth: 6"
- Height: 2"
- PDF: Custom America MP Ranger Thermal Printer Datasheet
- Manufacturer Part #: 911MM010100P33
- Warranty: Three Year
- Printing Method: Thermal
- Number of dots: 8 dots/mm
- Resolution: 203 DPI
- Supported Barcode: Codabar, Code 32, Code 39, Code 93, Code 128, EAN-8, EAN-13, GS1 dataBar Stacked, GS1 dataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked, ITF, UPC-A, UPC-E, Aztec, Aztec Rune, Data Matrix, PDF417, QRcode, Micro QRCode
- Printing Speed: 110mm/sec
- Character Set: PC437, PC850, PC860, PC863, PC865, PC866, PC858 (euro), Cinese esteso GB 18030-2000, Koreano PC949
- Paper width: 3" to 3 - 1/8" (76.2mm - 80 mm)
- Roll dimension: 4" max
- Sensors: Presence of paper, presence of alignment notch, head temperature, open cover, NFC
- Emulation: CustomPOS
- Interfaces: USB type-C 2.0 Full Speed, Wifi 802.11 b/g/n, Bluetooth 4.2 BLE
- Flash Memory: 8 MB Flash SPI+ 2 MB internal to the micro
- RAM Memory: 640kB + 8 MB SDRAM
- Graphic Memory: 16 kB
- Software Tools: 3 MB for logos (maximum width 576 dot) + 5 MB per font
- Driver: Windows® (32/64 bit) – only on request WHQL and silent installation
- Power supply: USB standard port from PC 5 V, 0.5 A (Slow charge)
- Battery pack: Li-ion 7.2 V 2.6 Ah 18.72 Wh
- Battery Cycles: 750
